HOSON Screen Printing Machine inline with Plane-type High-speed Die Bonder, Clip and Cutting Machine & Reflow Oven HAD205-PDCO

HOSON HAD205-PDCO
Screen Printing Machine inline with Plane-type High-speed Die Bonder, Clip and Cutting Machine & Reflow Oven

HAD205-P（支架刷膠機）（週期：20s）
適用於SMA,SMB,SMC,SMAF矩陣式多排支架產品等。
一、機型特性
刷膠工藝對膠量一致性/焊層控制較點膠和沾膠有明顯的優越性
堅固厚重的機構/網板座的可微調整設計，保證平臺和網板的相對水準
資料處理能力：；
1. 錫膏點位置/大小即時檢測表格顯示，位置/大小超出上下限報警停機
2. 錫膏點位置/大小資料保存可追蹤查詢；
3. 錫膏點位置/大小資料統計功能， ；
4. 錫膏點位置/大小資料檢測結果生成mapping供die attaching使用。
HAD205-P (Screen Printing Machine) (Cycle: 20 s)
It is compatible with SMA,SMB,SMC,SMAF matrix multi-row bracket products .
Product Features
To the consistency of the glue amount/ the controlling of weld layer void, the cementing possess obvious advantages over dispending and sticking way
Sturdy and heavy mechanism/ micro-adjustable stencil seat to ensure the relative level of the platform and the stencil
Data processing capabilities:
1. Real time detection table display of the solder paste mark position/ size, auto-shutdown alarming system if position/size exceeds the upper and lower limits;
2. Solder paste mark position/ size data preservation for querying anytime;
3. Solder paste mark position/ size data statistics function.;
4. Solder paste mark position/ size data detection results generate mapping for die attaching.
--------------------
HAD205-D（平面式雙頭高速固晶機）（週期：120ms）
適用於SMA,SMB,SMC,SMAF矩陣式多排支架產品等。
一、機型特性
1. 採用國際領先的雙固晶，雙晶片搜尋系統；
2. 採用直驅電機驅動邦頭
3. 採用線性電機驅動搜尋晶片平臺（X/Y）與送料平臺（B/C）
4. 晶框採用自動角度修正系統；
5. 採用真空漏晶檢測；
6. 採用自動式上下晶環、自動接駁台結構，有效提高了生產效率；
7. 工控機控制設備運行，簡化了自動化設備的操作；
8. 精准的設備化設備為企業提高生產效率，降低成本提供了有效保障，從而切實有效地提高了企業競爭力；
9. 精准的固晶位置及優良的一致性為後道工序提供了先天的保障
HAD205-D (Plane-type High-speed Die Bonder) (Cycle: 120ms)
It is compatible with SMA,SMB,SMC,SMAF matrix multi-row bracket products .
Product Features
1. International leading double die bond and double die searching system;
2. Linear motor is applied to drive bond head;
3. Linear motor will drive the die to search corresponding platform(X/Y) and corresponding loading platform (B/C);
4. Automatic chip alignment system is applied on the Crystal frame;
5. Vacuum die missing testing technology is adopted;
6. Automatic up & down crystal rings and automatic inspection conveyor system is applied to improve the production efficiency largely;
7. IPC will control the operation of equipment, simplifying the operation of automation equipment;
8. Sophisticated equipment will help improve your enterprise’s production efficiency and reduce relevant costs so as to provide effective guarantee and enhance the enterprise’s competitiveness;
9. Precise die bond location and excellent compatibility will guarantee the back-end processing.
--------------------
HAD205-C（全自動裁切機）（週期：90ms&取決客戶支架與跳線料帶的分佈及生產線綜合效率）
適用於SMA,SMB,SMC,SMAF矩陣式多排跳線料帶產品等
一、機型特性
1. Die dispensing
穩固的機構設計；點膠模組可擴展性適應客戶支架；高達4組點膠針頭，大大提高了點膠效率，每組點膠機構X/Y/Z向可調整方便調試維護；
2. Clip attaching
高精密度沖切模具可保證切口毛刺小於0.05mm；刀具壽命可達1kk次；clip bond force參數化設定可保證晶片不受損
資料處理能力：
1. 點膠點和Clip安裝點位置/大小即時檢測表格顯示，位置/大小超出上下限報警停機
2. 點膠點和Clip安裝點位置/大小資料保存可追蹤查詢
3. 點膠點和Clip安裝點位置/大小資料統計功能
4. 點膠點和Clip安裝點位置/大小資料檢測結果生成mapping供die attaching使用
HAD205-C (Clip and Cutting Machine) (Cycle: 90ms)
It is compatible with SMA,SMB,SMC,SMAF matrix multi-row bracket products .
Product Features
1. Die Dispensing
Stable mechanism design; Dispensing module can adapt to your holder; there are up to 4 sets of dispensing needles, which improved the dispensing efficiency greatly, each group of dispensing mechanism X / Y / Z direction are adjustable which facilitates debugging and maintenance;
2. Clip Attaching
The cutting burr is less than 0.05mm with the high-precision die-cutting mold; the tool life can reach to 1kk times; the clip bond force parameterization can protect the chip from damage.
Data processing capabilities:
1. Real time detection table display of the dispensing mark and clip mounting mark position/ size, auto-shutdown alarming system if position/size exceeds the upper or lower limits;
2. Dispensing mark and clip mounting mark position/ size data preservation for querying anytime;
3. Dispensing mark and clip mounting mark position/ size data statistics function;
4. Dispensing mark and clip mounting mark position/ size data detection results generate mapping for die attaching.
--------------------
HAD205-O（全自動接觸式烤爐）（週期：15-30s）
適用於SMA,SMB,SMC,SMAF矩陣式多排支架產品等。
一、機型特性
1. 產能 = 10~30 Sec. / 每一片(按錫膏商建議的Profile)
2. 低耗電（升溫時26KW/保溫時2KW）；低耗氣(100升/分)
3. 無氧化焊接 ，含氧量100ppm以下
4. 同一溫區 溫差小於10˚C ,可程式化之溫度曲線設定
5. 即時溫度監控
6. 不卡料之料片傳送機構
二、優越性：
1. 油煙處理 : 靜電式油煙收集方式，回流焊接時產生之廢氣經處理後可直排室內
2. 爐內腔體清潔保養週期 : 依錫膏品質/成份不同而異，如indium免清洗錫膏可一周清潔一次爐內腔體
3. 自動profile功能：系統可自動產生爐溫曲線，並可保存查詢
4. 爐蓋加熱：爐蓋備有加熱功能，保證焊油不在爐蓋上凝聚
5. 加熱棒：選用高品質加熱棒，保證同一溫區各點實測最高溫減最低溫小於或等於10℃
HAD205-O (Reflow Oven) (Cycle: 15-30s)
It is compatible with SMA,SMB,SMC,SMAF matrix multi-row bracket products .
Product Features
1. Capacity is 10~30 Sec. per piece (as recommended Profile by solder paste)
2. Low power consumption (26KW when warming up/2KW when keep warming); low gas consumption (100 liters/min)
3. No oxidation welding (nitrogen or nitrogen-hydrogen mixture), oxygen content below 100ppm
4. The temperature difference is less than10 ̊C in the same temperature zone, Programmable temperature curve setting
5. Instant temperature monitoring
6. Unloaded web transfer mechanism
Superiority
1. Lampblack treatment: Electrostatic lampblack collection, the exhaust gas generated during reflow soldering can be directly discharged indoors after being treated;
2. The cycle of furnace cavity cleaning and maintenance: Depending on the quality/component of the solder paste, such as indium no-clean solder paste which needs to clean the inner cavity once a week;
3. Automatic profile function: the system can generate the furnace temperature curve automatically and preserve the data for querying anytime;
4. Furnace cover heating: The furnace cover is equipped with heating function to preserve the welding oil from condense on the furnace cover.
5. Heating rod: the high-quality heating rod is adopted which can ensure that the actual measurement of the highest temperature minus the lowest temperature in each temperature zone is less than or equal to 10℃.
